THIS BLOCK QUALIFIES FOR FREE TRUCK FREIGHT ANYWHERE IN THE U.S.!
Dart 31837211 LS Next Cast Iron Block Specs:
Cylinder Bore as Shipped: 4.125in.
Max Cyl Bore Diam: 4.200in.
Main Bolt Style: 4-bolt
Main Caps Included: Yes
Engine Block Material: Steel
Rear Main Seal Style: 1-piece
Cam Brgs Included: No
Finished Cyl Bores: Yes
Raised Cam Location: No
Main Cap Material: Ductile Iron
Main Cap Fasteners: Yes
Engine Block Style: Stock/OEM standard deck
Deck Height: 9.240 in
Main Brgs Included: No
Freeze Plugs Included: Yes
Main Journal Type: LS Mains
The New Dart LS Next Engine Blocks are designed to eliminate the high RPM power loss and the problem of separate bays in the crankcase associated with the "Y-Block" design of the LS engine series. This has been accomplished by using the conventional style small and big block Chevy 4-bolt steel main caps with 7/16" bolts, full main webbing and crank barrel around a standard LS rotating assembly for maximum bottom end strength!
The cylinder barrels are extended by .375" at the bottom, providing the effective equivalent of a 9.615" deck height in terms of potential supported piston travel, while maintaining a standard 9.240" actual deck height for maximum compatibility with available components. This equates to greater piston support with long stroke combinations and allows for better piston designs to increase stability. While extra thick Siamese cylinder bores allow for large displacement capacity.
The oiling system has also been revised the stock internal main oil galley has been eliminated and a revised low restriction priority main oiling system is utilized. A ProStock/ProMod big block style stepped main oil galley measuring 9/16"-1/2"-7/16" is employed and increases volume but most importantly there is no loss of pressure or velocity at the front of the block.
At the top end of the block a 5/8" thick full deck design with six head bolts per cylinder is utilized to provide secure clamping strength and versatility for power adder applications. LSX style lifter bosses and guides are utilized while the provisions for oil restrictors in the lifter valley simplify the installation and removal of restrictors.
